Research & Development

Toronto-led group develops all-perovskite tandem solar cell with maximum efficiency

16 Nov 2022

Prototype 1cm cell yields record 2.19 eV; efficiency of 27.4% is new record for single-junction silicon cell.

A collaboration between the University of Toronto Engineering, Northwestern University, Evanston, Ilinois, and the University of Toledo, Toledo, Ohio, has resulted in an all-perovskite tandem solar cell with extremely high efficiency and record-setting voltage. The prototype device demonstrates the potential of this emerging photovoltaic technology to overcome key limits associated with traditional silicon solar cells, while also offering a lower manufacturing cost.

“Further improvements in the efficiency of solar cells are crucial for the ongoing decarbonization of our economy,” said University of Toronto Engineering Professor Ted Sargent, who recently joined the Department of Chemistry and the Department of Electrical and Computer Engineering at Northwestern University.

“While silicon solar cells have undergone impressive advances in recent years, there are inherent limitations to their efficiency and cost, arising from material properties. Perovskite technology can overcome these limitations, but until now, it had performed below its full potential. Our latest study identifies a key reason for this and points a way forward,” said Prof. Sargent.

Traditional solar cells are made from wafers of extremely high-purity silicon, which is energetically costly to produce. By contrast, perovskite solar cells are built from nano-sized crystals that can be dispersed into a liquid and spin-coated onto a surface using low-cost, well-established techniques.

Another advantage of perovskites is that by adjusting the thickness and chemical composition of the crystal films, manufacturers can selectively tune the wavelengths of light that get absorbed and converted into electricity, whereas silicon always absorbs the same part of the solar spectrum. The work is described in Nature.

Tandem dersign

The international team of researchers used two different layers of perovskite, each tuned to a different part of the solar spectrum, to produce what is known as a tandem solar cell. “In our cell, the top perovskite layer has a wider band gap, which absorbs well in the ultraviolet part of the spectrum, as well as some visible light,” said Chongwen Li, a postdoctoral researcher in Sargent’s lab and one of five co-lead authors on the paper.

He added, “The bottom layer has a narrow band gap, which is tuned more toward the infrared part of the spectrum. Between the two, we cover more of the spectrum than would be possible with silicon.”

The tandem design enables the cell to produce a very high open-circuit voltage, which in turn improves its efficiency. But the key innovation came when the team analyzed the interface between the perovskite layer, where light is absorbed and transformed into excited electrons, and the adjacent layer, known as the electron transport layer.

“What we found is that the electric field across the surface of the perovskite layer — we call it the surface potential — was not uniform,” said PhD student Aidan Maxwell, another co-lead author.

“The effect of this was that in some places, excited electrons were moving easily into the electron transport layer, but in others, they would just recombine with the holes they left behind. Those electrons were being lost to the circuit.”

To address this challenge, the team coated a substance known as 1,3-propanediammonium (PDA) onto the surface of the perovskite layer. Though the coating was only a few nanometres in thickness, it made a big difference. “PDA has a positive charge, and it is able to even out the surface potential,” says postdoctoral fellow Hao Chen, another of the co-lead authors.

“When we added the coating, we got much better energetic alignment of the perovskite layer with the electron transport layer, and that led to a big improvement on our overall efficiency.”

The team’s prototype solar cell measures one square centimetre in area, and produces an open-circuit voltage of 2.19 electron volts, which is a record for all-perovskite tandem solar cells. Its power conversion efficiency was measured at 27.4%, which is higher than the current record for traditional single-junction silicon solar cells. The cell was also independently certified at the National Renewable Energy Laboratory in Colorado, delivering an efficiency of 26.3%.

The team used industry standard methods to measure the stability of the new cell and found that it maintained 86% of its initial efficiency after 500 hours of continuous operation. “Continuing to advance the efficiency and stability of next-generation solar cells is a crucial priority for decarbonizing the electricity supply,” said Professor Alberto Salleo, Chair of the Department of Materials Science and Engineering at Stanford University, who was not involved in the study.

The researchers will now focus on further enhancing efficiency by increasing the current that runs through the cell, improving stability, and enlarging the area of the cell so that it can be scaled up to commercial proportions. The identification of the key role played by the interfaces between layers also points the way toward potential future improvements.
