Novel microendoscope design improves bio-imaging

02 Nov 2022

Probe with multiple focusing elements achieves better resolution with smaller diameters.

Microendoscopes using fiber optics are becoming increasingly important imaging tools, but they have physical limitations. They are essential for applications that require a long working distance, high resolution, and a minimum probe diameter.

A paper in IEEE Photonics Journal by Karol Karnowski of Poland’s International Centre for Translational Eye Research, Gavrielle Untracht of Technical University of Denmark, Michael Hackmann of University of Western Australia, Onur Cetinkaya of ICTER and David Sampson of the University of Surrey, UK, sheds new light on modern microendoscopes.

The researchers show that endoscopic imaging probes, particularly those for so-called side viewing, combining fiber-optic (GRIN) and spherical lenses, “offer excellent performance over the entire range of numerical apertures and open the way to a broader range of imaging applications”. The performance of endoscopic imaging probes is comparable to commonly used single focusing element probes.

Miniature fiber-optic probes, or micro-endoscopes, allow imaging of tissue microstructures deep into the specimen or patient. Endoscopic optical coherence tomography is particularly promising, say the partners, because “it is suitable for volumetric imaging of external tissues and the interior of organs”.

Three main ranges of fiber optic probes can be distinguished. Studies of large, hollow organs, such as those above the upper respiratory tract, require the largest imaging depth ranges (up to 15 mm or more from the probe surface), which can usually be achieved with low-resolution Gaussian beams (with a spot size in focus in the range of 30-100 μm).

The intermediate resolution range (10-30 μm) is helpful for broader applications, such as imaging the esophagus, smaller airways, blood vessels, bladder, ovaries, or ear canal. The biggest challenge is obtaining beams with a resolution better than 10 μm, potentially helpful for animal model studies.

When developing a probe, one must be mindful of design parameters' trade-offs and their impact on imaging performance. Optical systems with a large numerical aperture (high resolution) tend to have a shorter working distance. In addition, better resolution and longer working distance are more difficult to achieve as the probe diameter is reduced.

The authors note that “engineers are usually interested in minimizing the probe diameter for reduced perturbation to the sample and patient comfort”. A smaller probe means a more flexible catheter and, therefore, better tolerance of the test by the patient.

Thus, one of the best solutions is using monolithic fiber optic probes, whose diameter is limited by the thickness of the optical fibers. Such probes are characterized by ease of fabrication, thanks to fiber-optic welding technology, which avoids the need for tedious alignment and bonding of individual micro-optical components.

Scope for improvement

The most popular designs of fiber-optic imaging probes are those based on two types of focusing elements: GRIN fiber probes and ball lens probes. GRIN probes are easy to make, and their GRIN refractive power is not lost when the refractive index of the surrounding medium is close to that of the fiber used.

Commercially available GRIN fibers limit achievable designs. High resolution is tough to achieve with GRIN fibers with small core diameters. For lateral viewing probes, the curved surface of the fiber introduces distortion that can adversely affect imaging quality. Spherical BLP probes will not have this problem, but a sphere bigger than the fiber diameter is often required to achieve a resolution comparable to GFP probes.

One solution to improve the performance of probes is to use multiple light focusing elements, similar to the design of lenses with a long working distance. Studies have shown that combining numerous light-focusing elements provides better results for many imaging purposes. Probes with multiple focusing elements can achieve better resolution with smaller diameters while offering longer working distances without sacrificing resolution.

In their latest work, researchers led by Dr. Karnowski have shown that probes with two focusing elements using both GRIN segments and spherical lenses significantly improve the performance of monolithic fiber optic probes. Their first modeling results have already been shown at conferences in 2018 and 2019.

Analysis of the effect of GRIN fiber length and spherical lens size led to two interesting conclusions: for optimal results, the range of GRIN fiber length can be kept in the field of 0.25-0.4 pitch length (so-called pitch length); even if the working distance (WD) gain is not so significant for GBLP probes with high numerical aperture, the authors showed that the same or better performance in terms of working distance is achieved for a search with twice the diameter. Moreover, the novel GBLP probes offer higher resolution compared to BLP probes.
