Fast Tunable Laser

Eugenlight C-band tunable laser incorporates a monolithic InP chip that integrates a tunable SGDBR laser with a semiconductor optical amplifier (SOA). The SGDBR laser is an electronically tuned device that can address any wavelength in the C-Band. Since no mechanical or thermal adjustments are necessary, wavelength channel switching is very fast. The devices are packaged into a compact, low-profile hermetically sealed package, with an internal optical isolator.

Widely applied in Optical Communication; Spectroscopy; Sensing Technology. It maintains steady laser performance across extreme temperatures and supports round-the-clock running in industrial and outdoor scenarios. Fast electronic tuning allows flexible wavelength adjustment to match dynamic system requirements. Hermetic packaging blocks dust and humidity, boosting device lifespan and reducing regular maintenance expenses for system builders.

Key features:

Operation Case Temperature: -40~85℃;

Wavelength Tuning Range: C band;

Tuning Frequency: 200Hz;

Output Power: >13dBm;

Linewidth: <5 MHz;

Polarization Extinction Ratio: >20dB
