05 Oct 2017
University of Michigan researchers develop multi-dimensional spectroscopy technique to spot explosives, dangerous gases.College of Literature, Science and Arts, could be used in security systems in airports, for environmental monitoring of pollutants or even to detect hazardous chemicals on the battlefield.
The study, conducted by physics research fellow Bachana Lomsadze, has been published in Science.
Lomsadze and Cundiff's method combines two techniques that accelerate laser-based detection of chemicals – while doing it accurately. The first technique is based on the same principle as nuclear magnetic resonance spectroscopy, which uses radio frequencies to identify the structure of molecules.
Here, the researchers use a method called multi-dimensional coherent spectroscopy, or MDCS. MDCS uses ultrashort laser pulses to precisely identify gases. When the scientists bounce the laser pulses through the mixture of gases, those pulses can read the specific wavelengths of light that certain gases absorb.
Cundiff commented, "Sending a spectrum of through a sample will result in absorption of certain wavelengths leaving black stripes in the exiting transmitted light. Where the black stripes are gives you a barcode that tells you what kind of molecules are in the sample."
He added, “Scientists have been working on similar, simpler methods. Many significant molecules have rich spectra for certain wavelengths, in the visible but also infrared ranges. But this process becomes difficult when scientists try to identify gases in a mixture. Previously, scientists relied on comparing what they measured against a catalogue of molecules, a process that requires high performance computers and a significant amount of time."Our method takes from between about 15 minutes to a few hours using traditional approaches to MDCS. To speed up the process while maintaining accuracy, we combined MDCS with another method called dual comb spectroscopy.”
Frequency combs generate spectra consisting of equally-spaced sharp lines that are used as rulers to measure the spectral features of atoms and molecules with extremely high precision. Using two frequency combs (“dual”) provides an elegant way to rapidly acquire a high resolution spectrum without mechanical moving elements such as a corner cube, which usually limits how long it takes for the researchers to measure a spectrum.
"This approach could allow the method of multidimensional coherent spectroscopy to escape the lab and be used for practical applications such as detecting explosives or monitoring atmospheric constituents," Cundiff said.
Lomsadze and Cundiff applied their method to a vapor of rubidium atoms that contained two rubidium isotopes. The frequency difference between absorption lines for the two isotopes is too small to be observed using traditional approaches to MDCS, but by using combs, the U-M scientists were able to resolve these lines and assign the spectra of the isotopes based on how the energy levels were coupled to each other.
Next, the researchers plan to add a third laser that could even greater speed up their ability to identify gases. They also plan to use lasers based on fiber optics so that they can look further into infrared light, which would expand the number of chemicals they would be able to identify.
