Imec’s Si photonics 200mm wafer offers design flexibility.
Imec’s Si photonics 200mm wafer platform offers extensive design flexibility and includes: tight within-wafer silicon thickness variation 3sigma < 2.5nm; 3-level patterning of 220nm top Si layer (193nm optical lithography); poly-Si overlay and patterning (193nm optical lithography); and 3-level n-type implants and 3-level p-type implants in silicon.
