Optical memory cell achieves ‘record’ data storage density

27 Dec 2018

New device could enable computers that use optics and electrical signals to interact with data.

Researchers from the universities of Oxford, Exeter and Münster have demonstrated a new technique that can store more optical data in a smaller space than was previously possible on-chip. This technique improves upon the phase-change optical memory cell, which uses light to write and read data, and could offer a faster, more power-efficient form of memory for computers.

The scientists describe their new technique for all-optical data storage in the journal Optica.

Rather than using electrical signals to store data in one of two binary states as with conventional electronics-based computers, the optical memory cell uses light to store information. The researchers demonstrated optical memory with more than 32 states; the equivalent of 5 bits. They say that this development is an important step toward an all-optical computer.

Research team leader Harish Bhaskaran from Oxford University’s Department of Materials commented, “By bringing the speed-of-light-based data transmission to the circuit board, our all-optical memory could enable a hybrid computer chip that interacts with data both optically and electrically.”

The new work is part of a large Horizon 2020 project called Fun-COMP (Functionally-scaled Computing technology), which has brought academic and industrial partners together to develop groundbreaking hardware technologies.

Phase change

The optical memory cell uses light to encode information in a phase change material, a class of materials used to make re-writable CDs and DVDs. A laser heats portions of the material, which causes it to switch between states where all the atoms are ordered or disordered. Because these two states exhibit different optical indices of refraction, the data can be read using light.

Phase change materials can store data for a long time because they remain in the disordered or ordered state until illuminated again with the specific type of laser light originally used to write the data. Mixing different ratios of ordered and disordered states in an area of the material allows information to be stored in a continuum of levels instead of just a zero and a one as in traditional electronic memory.

The researchers accomplished the increased resolution by using a new technique they developed that uses laser light with a single, double-stepped pulse — two pulses put together into a rectangular-shaped pulse — to precisely control the melting and the crystallisation of the material.

Multi-level memory

The researchers showed that they could use their approach to reliably encode data on 34 levels, which is more than the 32 levels necessary for 5-bit programming.

“This accomplishment required understanding the interaction between the light and the material perfectly and then sending exactly the right sort of laser pulse necessary to achieve each level,” said Bhaskaran. “We have solved an extraordinarily difficult problem.”

The new technique could help overcome one of the bottlenecks limiting the speed of today’s computers: the link between the processor and the memory.

“A lot of work has gone into improving the communication between these two units using fiber optics,” Bhaskaran added. “However, linking these two units optically still requires expensive electro-optical conversions at both ends. Our memory cell could be used in a hybrid optical-electrical setup to eliminate the need for that conversion on the memory side by allowing data to be stored and retrieved optically.”

Next the researchers want to integrate multiple memory cells and individually program them, which would be required to make a working memory chip for a computer. The research groups have been working closely with Oxford University Innovation, the University’s innovation arm, to develop commercial opportunities arising from their research on photonic memory cells. The researchers say that they can already replicate the devices extremely well but will need to develop light signal processing techniques to integrate multiple optical memory cells.
